All the gentleness of a ribbon mixer combined with the performance of a paddle mixer. In addition, it also has all the advantages of a vertical mixer. Vertical mixers give users more batch flexibility, less loss of product due to residue left behind at discharge, and takes up less footprint.
The PerMix PD series High Speed Disperser (or Dissolver) is ideally designed to meet the demand of a broad spectrum of industrial applications for dispersing purpose of solid or liquid materials into liquid body.
The PD series High Speed Disperser works with the powerful high speed rotation of the saw disk impeller. Liquid or solid materials are subject to the high shear force at the periphery of the saw disc when the impeller is rotating at high speed, and they are dispersed quickly and efficiently into the liquid body after short time, homogeneous dispersion is produced.
The ease of operation and high efficiency of PerMix High Speed Dispersers reduce cost and operation time, and have proven themselves by providing the most economical solutions to a variety of dispersing problems.
Except the standard features of PerMix High Speed Disperser such as drum clamping arms, hydraulic lifting station, complete safety switches, variable speed controlling, etc, PerMix can also customize accessories to meet your specific needs, to those options including but not limited:
* Swiveling head which can serve several stationary drums
* Quick locking vacuum cover which allows easy dismantling
* Adjustable safety cover which protects against splashing and dust
* Impeller system with a static toothed ring for a very high shearing forces
* Mixing drums
* Double jacketed mixing drums
* Individually driven scrapers
The PerMix High Speed Disperser can be used for Dispersing, suspending, emulsifying, dissolving, homogenizing, mixing and breaking down agglomerates of high viscous materials, preparing paint batches, carbon paints, fillers, dispersion and coating paints, varnish pastes, printing inks, resin solutions, textile printing inks, preparing rubber, neoprene, resin and other types of adhesives, preparing filler dispersion, coating materials, insulation materials, bitumen based sealing materials, greases and lubricants.
Vacuum Sigma Mixers For All Applications & Size Requirements
PerMix has the most mixers models & sizes available of any mixer manufacturer & we lead the industry in innovation, performance, quality, & pricing, setting the standards others follow. This makes us the most disruptive brand, winning the hearts of our customers.
Here is our 1-liter vacuum sigma mixer that is complete with heating/cooling jacket. The unit was made with a very simple design in regards to manual tilting and features interior lighting, perfect for the customer’s needs & budget.
Come see the PerMix difference.
#permix #sigmamixers #engineering #innovation #foodmanufacturing #pharmaceuticalmanufacturing #chemicalmanufacturing #mixers #mixing #labequipment #labmixers
PerMix presents its Ribbon Mixer from the PRB series. The Ribbon Mixer is an efficient and versatile blending machine for the mixing of dry powders, granules and viscous pastes homogeneously. It is able to give a satisfying ‘ homogeneity grade ‘ for mixing jobs due to the special design of a mixing agitator with dual ribbons inside of a U-shaped working trough.
The PRB Ribbon Mixer is able to achieve a maximum “mixing ratio” of 1:500,000 which means you can get the desired mixture proportion of components in as small as 1 gram with a batch of 500kg
The Working of the PerMix PRB Ribbon Mixer consists of one electrical motor, one gearbox, and a shaft with double ribbons located in a U-Shaped vessel. The external & inner ribbons are designed in such a way that the powder materials are pushed to move from center to the two ends of the vessel, and meanwhile from ends to the center; besides, the powder materials are lifted up along the ribbon edges but then drop due to gravity. In such a three-dimensional way, the total powder can be mixed fast in the vessel. It asks for a short mixing time and relatively low power consumption.
Optional features such as heating/cooling jacket, spray nozzle, continuous operation, different types of ribbon (3 types), construction material, customized feeding & discharging, vacuum drying & de-aerating, extended height bases and external body with bead blasted or polished finish can be offered to you by PerMix.
Come see the PerMix difference at www.permixtec.com or www.permixmixrs.co.uk
#ribbonmixer #permix #mixers #ribbonblender #technology #engineering #industrialmixing #foodindustry #manufacturing #foodmanufacturing #pharmaceuticalmanufacturing #chemicalmanufacturing
PerMix Paddle Mixers = Best Value, Best Value = Innovation, Performance, Quality, & Price, Backed By The Best Warranty.
Since 1954 PerMix has been leading the industry, setting the standards others follow. PerMix’s philosophy focus on value and value to us means top-tier innovation combined with performance that is second to none. In addition, we focus on quality & price, winning the hearts of our customers worldwide. We then back it up with the best warranty in the industry, creating a sustainable brand that is disruptive by nature, driven by perfection.
Our recent build of this PerMix Paddle Mixer is a perfect example of our dedication to the above. Our Paddle Mixers are available in sizes from 5 liters to 30,000 liters and include options like heating & cooling jackets, vacuum, choppers, and more. Out of all the mixer manufacturers, PerMix features the most available models & types from them all.
Come see the PerMix difference by also visiting www.permixmixers.com in North America or www.permixmixers.mx in Mexico.
