Drying vs. Steam-Sterilising Powders in a Vacuum Mixer: A Deeper Look at Why Steam Injection Leads the Industry
PerMix UK | Advanced Powder Processing Solutions
Powder processors across the UK and Europe are demanding higher levels of safety, consistency, traceability, and product quality than ever before. Whether the industry is food, nutraceuticals, pharmaceuticals, botanicals, or speciality chemicals, the requirement is the same: dry the powder, sterilise the powder, and protect its functional properties — all with precision.
Two technologies dominate this space:
Both create value, yet they behave fundamentally differently inside the powder bed. Understanding the science behind these two approaches explains why direct steam injection is rapidly becoming the preferred method across regulated industries — and why PerMix UK has engineered a dedicated solution to meet this demand.
A jacketed vacuum mixer is a reliable tool for drying powders. It removes moisture efficiently by lowering the boiling point under vacuum while transferring heat from the jacket into the product as the agitator continually exposes new material to the vessel wall. For drying alone, it performs exceptionally well.
But sterilisation is another matter entirely.
Powders behave as natural thermal insulators. They trap air, form agglomerates, and heat by conduction — the slowest form of heat transfer. As a result:
• Powder near the vessel wall gets hot quickly.
• Powder in the centre heats slowly or unevenly.
• Clumps and micro-pockets become cold spots.
• Microbial kill rates remain inconsistent.
A jacketed vacuum mixer can deliver partial pasteurisation, but true validated sterilisation is difficult because microbial survival zones remain within the powder mass.
Cycle times also tend to be longer because all heat must travel from the vessel wall into the product. And longer thermal exposure increases the risk of damaging colour, aroma, nutrients, and volatility in sensitive ingredients.
For drying? Excellent.
For sterilising? Limited.
Direct steam injection transforms the mixer from a heated vessel into a highly controlled microbial kill environment. It changes heat transfer from slow conduction to rapid phase-change energy delivery — and the difference is dramatic.
1. Latent Heat Transfer
When steam condenses inside the powder bed, it instantly releases a large amount of energy. This is far more effective than relying on the heated vessel wall.
2. Steam Penetrates Where Heat Cannot
Under vacuum, steam flows into void spaces, across particle surfaces, into agglomerates, and through micro-channels that conduction cannot reach.
3. Moist Heat Has Higher Lethality Than Dry Heat
Microorganisms are destroyed faster, at lower temperatures, because moisture accelerates protein denaturation and cell wall rupture.
4. Moisture Is Temporary
The steam adds water, but vacuum immediately removes it during the drying phase, returning the powder to the required moisture specification.
5. Shorter Cycle Time
Steam rapidly achieves uniform temperatures, reducing both heating and sterilisation time. This means lower energy consumption and less thermal degradation.
The result is consistent, validated sterilisation with superior product preservation — ideal for spices, botanicals, proteins, infant nutrition, pharmaceuticals, herbal extracts, speciality powders, and many emerging clean-label applications.
• Jacket Only: Localised, slow, uneven
• Steam Injection: Rapid, uniform, penetrating
• Jacket Only: Partial, uncertain, dependent on slow conduction
• Steam Injection: Reliable, validated, high lethality
• Jacket Only: Long heat-up and soak periods
• Steam Injection: Much shorter, thanks to latent heat delivery
• Jacket Only: Higher risk of over-processing
• Steam Injection: Lower overall thermal exposure → better colour, aroma, and nutrient retention
• Jacket Only: Higher energy use due to long cycles
• Steam Injection: Lower energy total due to faster sterilisation
This is why steam sterilisation is the global standard in industries that demand microbial control with minimal product damage — and why more UK processors are shifting to this technology.
PerMix UK brings advanced engineering to a solution that unifies mixing, steam sterilising, vacuum drying, cooling, and discharge in a single, hygienic, efficient system.
Engineered Steam Injectors
Deliver uniform steam dispersion, ensuring complete penetration into the powder bed.
Vacuum-Enhanced Sterilisation Dynamics
Vacuum reduces steam temperature, encourages deep penetration, and accelerates drying after sterilisation.
Dual Heating System (Jacket + Steam)
Allows pre-heating, intense microbial kill, and rapid drying within one controlled thermal environment.
Accurate Thermal & Process Control
Fully automated PLC/HMI with recipe storage for validation, compliance, and repeatability.
Hygienic Construction for UK Food & Pharma Standards
316L stainless steel options, sanitary welds, CIP/SIP compatibility, and full traceability for highly regulated sectors.
Scalable from R&D to Production
Lab units right through to industrial systems — all built to deliver consistent results across scale.
Multifunctional Capability
Mixing, pasteurising, sterilising, drying, agglomeration, and even cooling — with a single machine footprint.
PerMix UK provides end-to-end support, including process guidance, validation assistance, and full lifecycle service. For UK manufacturers pursuing higher standards of quality assurance and microbial control, this technology is a strategic upgrade.
Vacuum drying with a jacket serves an important purpose — it efficiently removes moisture from powders. But true sterilisation requires more than heat against a vessel wall. It requires deep heat penetration, uniformity, moisture-assisted lethality, and precise thermal control.
Steam injection delivers exactly that.
And PerMix UK’s Steam Sterilisation Vacuum Mixer & Dryer combines advanced engineering, hygienic design, and intelligent processing control to give UK manufacturers a modern, reliable, high-performance solution for powder sterilisation and drying.
